TagReleaseCommit

The TagReleaseCommit job template creates a tag at the commit currently used by the pipeline run and then it triggers a new pipeline run for that tag, a.k.a tag pipeline or release pipeline.

Note

When the tag pipeline is launched, the pipeline is displayed in GitHub Actions with the name in the YAML file. In contrast, when a tag is manually added and pushed via Git on command line, the tag name is displayed.

Currently, no command, API or similar is known to add a tag and trigger a matching pipeline run, where the pipeline is named like the used tag. Thus, currently this job template has a slightly different behavior compared to manual tagging and pushing a tag to GitHub.

In addition, GitHub doesn’t support project access token, thus there is no solution to create a user independent token to emulate a manual push operation.

Instantiation

The following instantiation example depicts three jobs within a bigger pipeline. The prepare job derived from job template PrepareJob version @r6 figures out if a pipeline runs for a release merge-commit, for a tag or any other reason. Its outputs are used to either run a TriggerTaggedRelease job derived from job template TagReleaseCommit version @r6, or alternatively run the ReleasePage job derived from job template PublishReleaseNotes version @r6.

jobs:
  Prepare:
    uses: pyTooling/Actions/.github/workflows/PrepareJob.yml@r6

  # Other pipeline jobs

  TriggerTaggedRelease:
    uses: pyTooling/Actions/.github/workflows/TagReleaseCommit.yml@r6
    needs:
      - Prepare
    if: needs.Prepare.outputs.is_release_commit == 'true' && github.event_name != 'schedule'
    permissions:
      contents: write  # required for create tag
      actions:  write  # required for trigger workflow
    with:
      version:  ${{ needs.Prepare.outputs.version }}
      auto_tag: ${{ needs.Prepare.outputs.is_release_commit }}
    secrets: inherit

  ReleasePage:
    uses: pyTooling/Actions/.github/workflows/PublishReleaseNotes.yml@r6
    needs:
      - Prepare
    if: needs.Prepare.outputs.is_release_tag == 'true'
    permissions:
      contents: write
      actions:  write
    with:
      tag: ${{ needs.Prepare.outputs.version }}
    secrets: inherit

Parameter Summary

Goto input parameters

Parameter Name

Required

Type

Default

ubuntu_image

no

string

'ubuntu-24.04'

version

yes

string

— — — —

auto_tag

yes

string

— — — —

workflow

no

string

'Pipeline.yml'

Goto secrets

This job template needs no secrets.

Goto output parameters

This job template has no output parameters.

Input Parameters

ubuntu_image

Type:

string

Required:

no

Default Value:

'ubuntu-24.04'

Possible Values:

See actions/runner-images - Available Images for available Ubuntu image versions.

Description:

Name of the Ubuntu image used to run this job.

version

Type:

string

Required:

yes

Default Value:

— — — —

Possible Values:

Any valid Git tag name.

Description:

The version string to be used for tagging.

auto_tag

Type:

string

Required:

yes

Default Value:

— — — —

Possible Values:

'false', 'true'`

Description:

If true, tag the current commit.

workflow

Type:

string

Required:

no

Default Value:

'Pipeline.yml'

Possible Values:

Any valid GitHub Action pipeline filename.

Description:

Github Action pipeline (workflow) to trigger after tag creation.

Note

Compared to manual tagging and pushing a tag, where a pipeline is triggered automatically, here a pipeline must be trigger separately by API. Therefore the pipeline doesn’t run with the name of the tag, but with the name specified within the workflow YAML file.

Secrets

This job template needs no secrets.

Outputs

This job template has no output parameters.

Optimizations

This template offers no optimizations (reduced job runtime).
